  • INGERSOLL 2J1R040R02 Milling Cutter 90.0° 1.575 Shell Arbor 0.6300 4 Flute Coolant 0.4724 Max DOC 1.574 OAL
Picture of INGERSOLL 2J1R040R02 Milling Cutter 90.0° 1.575 Shell Arbor 0.6300 4 Flute Coolant 0.4724 Max DOC 1.574 OAL

INGERSOLL 2J1R040R02 Milling Cutter 90.0° 1.575 Shell Arbor 0.6300 4 Flute Coolant 0.4724 Max DOC 1.574 OAL

ANSI: 2J1R040R02

ISO: 2J1R040R02

Need Assistance or Service? Please call 262-251-4020

Manufacturer: INGERSOLL
SKU: ING3057577
Delivery date: 3-5 days
$572.13
Products specifications
Attribute name Attribute value
General Product Information
Insert/Tool Tool
Application Pocket Milling, Face Milling, Ramp Milling, Side Milling, Slot Milling
Insert Application Roughing, Semi Finishing, Finishing
Package Size 1
Insert Type Positive
Made In USA No
Shipping State Illinois
Dimensional Specifications
Cut Dia Min 1.5750 40.01MM
Tool Material Steel
Flutes/Inserts 4
Depth Of Cut Max 0.4724
Insert Size Ic 13
Machine Side Connection Size 0.6299 16.00MM
Cutter Dia 1.5750 40.01MM
Machine Side Connection Type Face Mill/Shell Mill
Overall Len 1.5748 40.00MM
Cutting & Machining Properties
Coolant Thru Yes
Insert Shape/Cutter Pocket Shape Parallelogram
Insert Style BO
Max Ramp Angle 3.20°
