  • INGERSOLL 2J1R040R00 Milling Cutter 90.0° 1.575 Shell Arbor 0.6300 5 Flute Coolant 0.4724 Max DOC 1.574 OAL
Picture of INGERSOLL 2J1R040R00 Milling Cutter 90.0° 1.575 Shell Arbor 0.6300 5 Flute Coolant 0.4724 Max DOC 1.574 OAL

INGERSOLL 2J1R040R00 Milling Cutter 90.0° 1.575 Shell Arbor 0.6300 5 Flute Coolant 0.4724 Max DOC 1.574 OAL

ANSI: 2J1R040R00

ISO: 2J1R040R00

Need Assistance or Service? Please call 262-251-4020

Manufacturer: INGERSOLL
SKU: ING3074948
Delivery date: 3-5 days
$606.67
Products specifications
Attribute name Attribute value
General Product Information
Insert Application Roughing, Finishing, Semi Finishing
Made In USA No
Insert Type Positive
Application Face Milling, Slot Milling, Ramp Milling, Side Milling, Pocket Milling
Package Size 1
Insert/Tool Tool
Shipping State Illinois
Dimensional Specifications
Machine Side Connection Type Face Mill/Shell Mill
Machine Side Connection Size 0.6299 16.00MM
Depth Of Cut Max 0.4724
Cut Dia Min 1.5750 40.01MM
Insert Size Ic 13
Cutter Dia 1.5750 40.01MM
Tool Material Steel
Overall Len 1.5748 40.00MM
Flutes/Inserts 5
Cutting & Machining Properties
Insert Style BO
Max Ramp Angle 3.20°
Coolant Thru Yes
Insert Shape/Cutter Pocket Shape Parallelogram
