  • INGERSOLL 2J1R-25R01 Milling Cutter 90.0° 2.500 Shell Arbor 0.7500 6 Flute Coolant 0.47 Max DOC 1.570 OAL
Picture of INGERSOLL 2J1R-25R01 Milling Cutter 90.0° 2.500 Shell Arbor 0.7500 6 Flute Coolant 0.47 Max DOC 1.570 OAL

INGERSOLL 2J1R-25R01 Milling Cutter 90.0° 2.500 Shell Arbor 0.7500 6 Flute Coolant 0.47 Max DOC 1.570 OAL

ANSI: 2J1R-25R01

ISO: 2J1R-25R01

Need Assistance or Service? Please call 262-251-4020

Manufacturer: INGERSOLL
SKU: ING2916675
Delivery date: 3-5 days
$714.00

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Insert Application Roughing, Finishing, Semi Finishing
Made In USA No
Insert Type Positive
Application Ramp Milling, Slot Milling, Pocket Milling, Side Milling, Face Milling
Shipping State Illinois
Insert/Tool Tool
Package Size 1
Dimensional Specifications
Machine Side Connection Type Face Mill/Shell Mill
Tool Material Steel
Overall Len 1.5700 39.88MM
Cutter Dia 2.5000 63.50MM - 2-1/2
Machine Side Connection Size 0.7500 19.05MM
Cut Dia Min 2.5000 63.50MM - 2-1/2
Depth Of Cut Max 0.4700
Flutes/Inserts 6
Insert Size Ic 13
Cutting & Machining Properties
Insert Style BO
Coolant Thru Yes
Max Ramp Angle 1.10°
Insert Shape/Cutter Pocket Shape Parallelogram
