  • INGERSOLL 2J1R-20R02 Milling Cutter 90.0° 2.000 Shell Arbor 0.7500 6 Flute Coolant 0.47 Max DOC 1.570 OAL
Picture of INGERSOLL 2J1R-20R02 Milling Cutter 90.0° 2.000 Shell Arbor 0.7500 6 Flute Coolant 0.47 Max DOC 1.570 OAL

INGERSOLL 2J1R-20R02 Milling Cutter 90.0° 2.000 Shell Arbor 0.7500 6 Flute Coolant 0.47 Max DOC 1.570 OAL

ANSI: 2J1R-20R02

ISO: 2J1R-20R02

Need Assistance or Service? Please call 262-251-4020

Manufacturer: INGERSOLL
SKU: ING2916674
Delivery date: 3-5 days
$679.47

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Insert Application Roughing, Semi Finishing, Finishing
Made In USA No
Application Ramp Milling, Side Milling, Pocket Milling, Face Milling, Slot Milling
Package Size 1
Insert/Tool Tool
Shipping State Illinois
Insert Type Positive
Dimensional Specifications
Machine Side Connection Type Face Mill/Shell Mill
Depth Of Cut Max 0.4700
Cutter Dia 2.0000 50.80MM
Flutes/Inserts 6
Insert Size Ic 13
Tool Material Steel
Machine Side Connection Size 0.7500 19.05MM
Overall Len 1.5700 39.88MM
Cut Dia Min 2.0000 50.80MM
Cutting & Machining Properties
Coolant Thru Yes
Insert Style BO
Max Ramp Angle 1.50°
Insert Shape/Cutter Pocket Shape Parallelogram
