  • INGERSOLL 2J1P100R00 Milling Cutter 90.0° 3.937 Shell Arbor 1.2598 12 Flute Coolant 0.3543 Max DOC 1.968 OAL
Picture of INGERSOLL 2J1P100R00 Milling Cutter 90.0° 3.937 Shell Arbor 1.2598 12 Flute Coolant 0.3543 Max DOC 1.968 OAL

INGERSOLL 2J1P100R00 Milling Cutter 90.0° 3.937 Shell Arbor 1.2598 12 Flute Coolant 0.3543 Max DOC 1.968 OAL

ANSI: 2J1P100R00

ISO: 2J1P100R00

Need Assistance or Service? Please call 262-251-4020

Manufacturer: INGERSOLL
SKU: ING5879895
Delivery date: 3-5 days
$1,157.33
Products specifications
Attribute name Attribute value
General Product Information
Insert Application Finishing, Semi Finishing, Roughing
Insert Type Positive
Application Face Milling, Pocket Milling, Side Milling, Ramp Milling, Slot Milling
Package Size 1
Made In USA No
Shipping State Illinois
Insert/Tool Tool
Dimensional Specifications
Insert Size Ic 9
Depth Of Cut Max 0.3543
Cutter Dia 3.9370 100.00MM
Machine Side Connection Type Face Mill/Shell Mill
Machine Side Connection Size 1.2598 32.00MM
Overall Len 1.9685 50.00MM
Cut Dia Min 3.9370 100.00MM
Tool Material Steel
Flutes/Inserts 12
Cutting & Machining Properties
Insert Shape/Cutter Pocket Shape Parallelogram
Insert Style BO
Coolant Thru Yes
Max Ramp Angle 0.50°
