  • INGERSOLL 2J1P080R00 Milling Cutter 90.0° 3.150 Shell Arbor 0.6300 10 Flute Coolant 0.3543 Max DOC 1.968 OAL
Picture of INGERSOLL 2J1P080R00 Milling Cutter 90.0° 3.150 Shell Arbor 0.6300 10 Flute Coolant 0.3543 Max DOC 1.968 OAL

INGERSOLL 2J1P080R00 Milling Cutter 90.0° 3.150 Shell Arbor 0.6300 10 Flute Coolant 0.3543 Max DOC 1.968 OAL

ANSI: 2J1P080R00

ISO: 2J1P080R00

Need Assistance or Service? Please call 262-251-4020

Manufacturer: INGERSOLL
SKU: ING5879894
Delivery date: 3-5 days
$980.00
Products specifications
Attribute name Attribute value
General Product Information
Application Pocket Milling, Face Milling, Ramp Milling, Slot Milling, Side Milling
Shipping State Illinois
Insert Application Roughing, Finishing, Semi Finishing
Made In USA No
Package Size 1
Insert Type Positive
Insert/Tool Tool
Dimensional Specifications
Tool Material Steel
Cutter Dia 3.1500 80.01MM
Machine Side Connection Type Face Mill/Shell Mill
Depth Of Cut Max 0.3543
Cut Dia Min 3.1500 80.01MM
Insert Size Ic 9
Machine Side Connection Size 0.6299 16.00MM
Overall Len 1.9685 50.00MM
Flutes/Inserts 10
Cutting & Machining Properties
Insert Style BO
Max Ramp Angle 0.60°
Insert Shape/Cutter Pocket Shape Parallelogram
Coolant Thru Yes
