Picture of INGERSOLL 2J1P-30R01 Milling Cutter 90.0° 3.000 Shell Arbor 1.0000 9 Flute Coolant 1.750 OAL

INGERSOLL 2J1P-30R01 Milling Cutter 90.0° 3.000 Shell Arbor 1.0000 9 Flute Coolant 1.750 OAL

ANSI: 2J1P-30R01

ISO: 2J1P-30R01

Need Assistance or Service? Please call 262-251-4020

Manufacturer: INGERSOLL
SKU: ING3028213
Delivery date: 3-5 days
$854.93

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Insert Application Roughing, Semi Finishing, Finishing
Made In USA No
Application Ramp Milling, Side Milling, Face Milling, Slot Milling, Pocket Milling
Package Size 1
Insert Type Positive
Insert/Tool Tool
Shipping State Illinois
Dimensional Specifications
Cut Dia Min 3.0000 76.20MM
Machine Side Connection Type Face Mill/Shell Mill
Machine Side Connection Size 1.0000 25.40MM
Flutes/Inserts 9
Overall Len 1.7500 44.45MM
Insert Size Ic 9
Cutter Dia 3.0000 76.20MM
Tool Material Steel
Cutting & Machining Properties
Coolant Thru Yes
Insert Style BO
Max Ramp Angle 0.70°
Insert Shape/Cutter Pocket Shape Parallelogram
