Picture of INGERSOLL 2J1P-25R01 Milling Cutter 90.0° 2.500 Shell Arbor 0.7500 8 Flute Coolant 1.570 OAL

INGERSOLL 2J1P-25R01 Milling Cutter 90.0° 2.500 Shell Arbor 0.7500 8 Flute Coolant 1.570 OAL

ANSI: 2J1P-25R01

ISO: 2J1P-25R01

Need Assistance or Service? Please call 262-251-4020

Manufacturer: INGERSOLL
SKU: ING2917451
Delivery date: 3-5 days
$761.60

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Insert Application Finishing, Semi Finishing, Roughing
Insert Type Positive
Application Face Milling, Pocket Milling, Side Milling, Ramp Milling, Slot Milling
Package Size 1
Made In USA No
Shipping State Illinois
Insert/Tool Tool
Dimensional Specifications
Insert Size Ic 9
Machine Side Connection Type Face Mill/Shell Mill
Tool Material Steel
Cut Dia Min 2.5000 63.50MM - 2-1/2
Flutes/Inserts 8
Cutter Dia 2.5000 63.50MM - 2-1/2
Machine Side Connection Size 0.7500 19.05MM
Overall Len 1.5700 39.88MM
Cutting & Machining Properties
Insert Style BO
Insert Shape/Cutter Pocket Shape Parallelogram
Max Ramp Angle 1.00°
Coolant Thru Yes
