Picture of INGERSOLL 2J1P-15R01 Milling Cutter 90.0° 1.500 Shell Arbor 0.5000 6 Flute Coolant 1.570 OAL

INGERSOLL 2J1P-15R01 Milling Cutter 90.0° 1.500 Shell Arbor 0.5000 6 Flute Coolant 1.570 OAL

ANSI: 2J1P-15R01

ISO: 2J1P-15R01

Need Assistance or Service? Please call 262-251-4020

Manufacturer: INGERSOLL
SKU: ING3028211
Delivery date: 3-5 days
$527.33

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Insert Application Finishing, Semi Finishing, Roughing
Insert Type Positive
Application Face Milling, Pocket Milling, Side Milling, Ramp Milling, Slot Milling
Package Size 1
Made In USA No
Shipping State Illinois
Insert/Tool Tool
Dimensional Specifications
Insert Size Ic 9
Cut Dia Min 1.5000 38.10MM - 1-1/2
Machine Side Connection Size 0.5000 12.70MM
Machine Side Connection Type Face Mill/Shell Mill
Cutter Dia 1.5000 38.10MM - 1-1/2
Flutes/Inserts 6
Tool Material Steel
Overall Len 1.5700 39.88MM
Cutting & Machining Properties
Insert Style BO
Insert Shape/Cutter Pocket Shape Parallelogram
Max Ramp Angle 2.40°
Coolant Thru Yes
