  • INGERSOLL 22Q3R-17020D4R01 Milling Cutter 15.0° 1.750 Cylindrical 1.2500 4 Flute Coolant 0.338 Max DOC 2.000 OAL
Picture of INGERSOLL 22Q3R-17020D4R01 Milling Cutter 15.0° 1.750 Cylindrical 1.2500 4 Flute Coolant 0.338 Max DOC 2.000 OAL

INGERSOLL 22Q3R-17020D4R01 Milling Cutter 15.0° 1.750 Cylindrical 1.2500 4 Flute Coolant 0.338 Max DOC 2.000 OAL

ANSI: 22Q3R-17020D4R01

ISO: 22Q3R-17020D4R01

Need Assistance or Service? Please call 262-251-4020

Manufacturer: INGERSOLL
SKU: ING2924443
Delivery date: 3-5 days
$1,120.00

Details

MULTI INSERT CHAMFER MILLS, USED FOR LONGER CUTS. VERY LIMITED MIS-MATCH.

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Insert Type Positive
Insert Application Semi Finishing, Roughing
Insert/Tool Tool
Application Chamfering, Long Edge Chamfering
Made In USA No
Shipping State Illinois
Package Size 1
Dimensional Specifications
Insert Size Ic 13
Cut Dia Max 4.3050 109.35MM
Tool Material Steel
Machine Side Connection Size 1.2500 31.75MM
Overall Len 2.0000 50.80MM
Depth Of Cut Max 0.3380
Cut Dia Min 1.7500 44.45MM - 1-3/4
Machine Side Connection Type Cylindrical
Cutter Dia 1.7500 44.45MM - 1-3/4
Shank/Pilot Dia 1.2500 31.75MM - 1-1/4
Flutes/Inserts 4
Cutting & Machining Properties
Insert Shape/Cutter Pocket Shape Parallelogram
Insert Style BO
Coolant Thru Yes
