  • INGERSOLL 22L3R-17020D3R01 Milling Cutter 60.0° 1.750 Cylindrical 1.0000 4 Flute Coolant 1.29 Max DOC 2.000 OAL
Picture of INGERSOLL 22L3R-17020D3R01 Milling Cutter 60.0° 1.750 Cylindrical 1.0000 4 Flute Coolant 1.29 Max DOC 2.000 OAL

INGERSOLL 22L3R-17020D3R01 Milling Cutter 60.0° 1.750 Cylindrical 1.0000 4 Flute Coolant 1.29 Max DOC 2.000 OAL

ANSI: 22L3R-17020D3R01

ISO: 22L3R-17020D3R01

Need Assistance or Service? Please call 262-251-4020

Manufacturer: INGERSOLL
SKU: ING2924306
Delivery date: 3-5 days
$1,120.00

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Insert/Tool Tool
Application Chamfering, Long Edge Chamfering
Insert Application Semi Finishing
Insert Type Positive
Package Size 1
Made In USA No
Shipping State Illinois
Dimensional Specifications
Cut Dia Min 1.7500 44.45MM - 1-3/4
Machine Side Connection Type Cylindrical
Machine Side Connection Size 1.0000 25.40MM
Insert Size Ic 13
Cut Dia Max 2.4450 62.10MM
Flutes/Inserts 4
Shank/Pilot Dia 1.0000 25.40MM
Depth Of Cut Max 1.2900
Cutter Dia 1.7500 44.45MM - 1-3/4
Tool Material Steel
Overall Len 2.0000 50.80MM
Cutting & Machining Properties
Coolant Thru Yes
Insert Shape/Cutter Pocket Shape Parallelogram
Insert Style BO
