  • INGERSOLL 1WJ1F-1001780R01 Milling Cutter 90.0° 1.000 Cylindrical 1.0000 2 Flute Coolant 0.22 Max DOC 4.000 OAL
Picture of INGERSOLL 1WJ1F-1001780R01 Milling Cutter 90.0° 1.000 Cylindrical 1.0000 2 Flute Coolant 0.22 Max DOC 4.000 OAL

INGERSOLL 1WJ1F-1001780R01 Milling Cutter 90.0° 1.000 Cylindrical 1.0000 2 Flute Coolant 0.22 Max DOC 4.000 OAL

ANSI: 1WJ1F-1001780R01

ISO: 1WJ1F-1001780R01

Need Assistance or Service? Please call 262-251-4020

Manufacturer: INGERSOLL
SKU: ING2911303
Delivery date: 3-5 days
$312.67

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Application Side Milling, Face Milling
Package Size 1
Insert Type Negative
Made In USA No
Insert/Tool Tool
Shipping State Illinois
Insert Application Semi Finishing
Dimensional Specifications
Overall Len 4.0000 101.60MM
Depth Of Cut Max 0.2200
Shank/Pilot Dia 1.0000 25.40MM
Insert Size Ic 6
Flutes/Inserts 2
Cutter Dia 1.0000 25.40MM
Cut Dia Min 1.0000 25.40MM
Tool Material Steel
Machine Side Connection Type Cylindrical
Machine Side Connection Size 1.0000 25.40MM
Cutting & Machining Properties
Insert Style WN
Max Ramp Angle 2.70°
Coolant Thru Yes
Insert Shape/Cutter Pocket Shape Trigon
