  • INGERSOLL 1TJ1Q-1001784R01 Milling Cutter 90.0° 1.000 Weldon 0.7500 2 Flute Coolant 0.43 Max DOC 3.750 OAL
Picture of INGERSOLL 1TJ1Q-1001784R01 Milling Cutter 90.0° 1.000 Weldon 0.7500 2 Flute Coolant 0.43 Max DOC 3.750 OAL

INGERSOLL 1TJ1Q-1001784R01 Milling Cutter 90.0° 1.000 Weldon 0.7500 2 Flute Coolant 0.43 Max DOC 3.750 OAL

ANSI: 1TJ1Q-1001784R01

ISO: 1TJ1Q-1001784R01

Need Assistance or Service? Please call 262-251-4020

Manufacturer: INGERSOLL
SKU: ING3031338
Delivery date: 3-5 days
$295.87

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Shipping State Illinois
Application Side Milling, Face Milling
Insert Type Negative
Insert Application Roughing, Semi Finishing
Made In USA No
Insert/Tool Tool
Package Size 1
Dimensional Specifications
Depth Of Cut Max 0.4300
Cutter Dia 1.0000 25.40MM
Cut Dia Min 1.0000 25.40MM
Tool Material Steel
Insert Size Ic 12
Flutes/Inserts 2
Machine Side Connection Size 0.7500 19.05MM
Shank/Pilot Dia 0.7500 19.05MM - 3/4
Machine Side Connection Type Weldon
Overall Len 3.7500 95.25MM
Cutting & Machining Properties
Max Ramp Angle 1.40°
Coolant Thru Yes
Insert Shape/Cutter Pocket Shape Parallelogram
Insert Style AN
