Picture of INGERSOLL 1TJ1Q-10015X7R01 Milling Cutter 90.0° 1.000 Screw M12 2 Flute Coolant 0.43 Max DOC

INGERSOLL 1TJ1Q-10015X7R01 Milling Cutter 90.0° 1.000 Screw M12 2 Flute Coolant 0.43 Max DOC

ANSI: 1TJ1Q-10015X7R01

ISO: 1TJ1Q-10015X7R01

Need Assistance or Service? Please call 262-251-4020

Manufacturer: INGERSOLL
SKU: ING3031346
Delivery date: 3-5 days
$341.60

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Application Side Milling, Face Milling
Insert Type Negative
Insert Application Roughing, Semi Finishing
Made In USA No
Shipping State Illinois
Insert/Tool Tool
Package Size 1
Dimensional Specifications
Machine Side Connection Type Screw On
Machine Side Connection Size M12
Cutter Dia 1.0000 25.40MM
Depth Of Cut Max 0.4300
Cut Dia Min 1.0000 25.40MM
Tool Material Steel
Insert Size Ic 12
Flutes/Inserts 2
Cutting & Machining Properties
Max Ramp Angle 1.40°
Insert Shape/Cutter Pocket Shape Parallelogram
Insert Style AN
Coolant Thru Yes
