  • INGERSOLL 1TJ1C-05012S4R01 Milling Cutter 90.0°, Back Draft 0.500 Cylindrical 0.5000 2 Flute Coolant 0.18 Max DOC 3.000 OAL
Picture of INGERSOLL 1TJ1C-05012S4R01 Milling Cutter 90.0°, Back Draft 0.500 Cylindrical 0.5000 2 Flute Coolant 0.18 Max DOC 3.000 OAL

INGERSOLL 1TJ1C-05012S4R01 Milling Cutter 90.0°, Back Draft 0.500 Cylindrical 0.5000 2 Flute Coolant 0.18 Max DOC 3.000 OAL

ANSI: 1TJ1C-05012S4R01

ISO: 1TJ1C-05012S4R01

Need Assistance or Service? Please call 262-251-4020

Manufacturer: INGERSOLL
SKU: ING2910938
Delivery date: 3-5 days
$258.53

File Downloads

DXFSTPSTPL

Products specifications
Attribute name Attribute value
General Product Information
Insert Application Roughing, Finishing, Semi Finishing
Package Size 1
Insert/Tool Tool
Application Face Milling, Profile Milling, Ramp Milling, Slot Milling, Copy Milling, Feed Milling
Insert Type Negative
Made In USA No
Shipping State Illinois
Dimensional Specifications
Flutes/Inserts 2
Insert Size Ic 5
Cut Dia Min 0.5000 12.70MM - 1/2
Tool Material Steel
Machine Side Connection Size 0.5000 12.70MM
Overall Len 3.0000 76.20MM
Depth Of Cut Max 0.1800
Machine Side Connection Type Cylindrical
Cutter Dia 0.5000 12.70MM - 1/2
Shank/Pilot Dia 0.5000 12.70MM - 1/2
Cutting & Machining Properties
Insert Shape/Cutter Pocket Shape Parallelogram
Max Ramp Angle 6.90°
Insert Style EN
Coolant Thru Yes
