  • INGERSOLL 1SJ1Y-1003280R01 Milling Cutter 90.0° 1.000 Cylindrical 1.0000 3 Flute Coolant 0.31 Max DOC 5.500 OAL
Picture of INGERSOLL 1SJ1Y-1003280R01 Milling Cutter 90.0° 1.000 Cylindrical 1.0000 3 Flute Coolant 0.31 Max DOC 5.500 OAL

INGERSOLL 1SJ1Y-1003280R01 Milling Cutter 90.0° 1.000 Cylindrical 1.0000 3 Flute Coolant 0.31 Max DOC 5.500 OAL

ANSI: 1SJ1Y-1003280R01

ISO: 1SJ1Y-1003280R01

Need Assistance or Service? Please call 262-251-4020

Manufacturer: INGERSOLL
SKU: ING3030105
Delivery date: 3-5 days
$394.80

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Insert Type Negative
Insert Application Roughing, Semi Finishing
Made In USA No
Shipping State Illinois
Package Size 1
Application Face Milling, Side Milling
Insert/Tool Tool
Dimensional Specifications
Cutter Dia 1.0000 25.40MM
Overall Len 5.5000 139.70MM
Flutes/Inserts 3
Depth Of Cut Max 0.3100
Insert Size Ic 21
Machine Side Connection Type Cylindrical
Machine Side Connection Size 1.0000 25.40MM
Shank/Pilot Dia 1.0000 25.40MM
Cut Dia Min 1.0000 25.40MM
Tool Material Steel
Cutting & Machining Properties
Coolant Thru Yes
Insert Shape/Cutter Pocket Shape Rectagonal
Insert Style DG
