  • INGERSOLL 1SJ1Y-0703280R01 Milling Cutter 90.0° 0.750 Cylindrical 1.0000 2 Flute Coolant 0.31 Max DOC 5.500 OAL
Picture of INGERSOLL 1SJ1Y-0703280R01 Milling Cutter 90.0° 0.750 Cylindrical 1.0000 2 Flute Coolant 0.31 Max DOC 5.500 OAL

INGERSOLL 1SJ1Y-0703280R01 Milling Cutter 90.0° 0.750 Cylindrical 1.0000 2 Flute Coolant 0.31 Max DOC 5.500 OAL

ANSI: 1SJ1Y-0703280R01

ISO: 1SJ1Y-0703280R01

Need Assistance or Service? Please call 262-251-4020

Manufacturer: INGERSOLL
SKU: ING3030103
Delivery date: 3-5 days
Call (262) 251-4020 for pricing

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Application Side Milling, Face Milling
Insert Application Roughing, Semi Finishing
Made In USA No
Package Size 1
Insert/Tool Tool
Insert Type Negative
Shipping State Illinois
Dimensional Specifications
Depth Of Cut Max 0.3100
Shank/Pilot Dia 1.0000 25.40MM
Flutes/Inserts 2
Cut Dia Min 0.7500 19.05MM - 3/4
Cutter Dia 0.7500 19.05MM - 3/4
Overall Len 5.5000 139.70MM
Insert Size Ic 21
Machine Side Connection Type Cylindrical
Machine Side Connection Size 1.0000 25.40MM
Tool Material Steel
Cutting & Machining Properties
Insert Shape/Cutter Pocket Shape Rectagonal
Coolant Thru Yes
Insert Style DG
