  • INGERSOLL 1SJ1Y-0701284R01 Milling Cutter 90.0° 0.750 Weldon 0.7500 2 Flute Coolant 0.31 Max DOC 3.250 OAL
Picture of INGERSOLL 1SJ1Y-0701284R01 Milling Cutter 90.0° 0.750 Weldon 0.7500 2 Flute Coolant 0.31 Max DOC 3.250 OAL

INGERSOLL 1SJ1Y-0701284R01 Milling Cutter 90.0° 0.750 Weldon 0.7500 2 Flute Coolant 0.31 Max DOC 3.250 OAL

ANSI: 1SJ1Y-0701284R01

ISO: 1SJ1Y-0701284R01

Need Assistance or Service? Please call 262-251-4020

Manufacturer: INGERSOLL
SKU: ING3030108
Delivery date: 3-5 days
$347.20

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Insert/Tool Tool
Insert Application Roughing, Semi Finishing
Package Size 1
Application Side Milling, Face Milling
Insert Type Negative
Made In USA No
Shipping State Illinois
Dimensional Specifications
Cutter Dia 0.7500 19.05MM - 3/4
Tool Material Steel
Machine Side Connection Size 0.7500 19.05MM
Flutes/Inserts 2
Insert Size Ic 21
Machine Side Connection Type Weldon
Cut Dia Min 0.7500 19.05MM - 3/4
Shank/Pilot Dia 0.7500 19.05MM - 3/4
Overall Len 3.2500 82.55MM
Depth Of Cut Max 0.3100
Cutting & Machining Properties
Insert Style DG
Coolant Thru Yes
Insert Shape/Cutter Pocket Shape Rectagonal
