  • INGERSOLL 1SJ1F-1503781R01 Milling Cutter 90.0° 1.500 Cylindrical 1.2500 3 Flute Coolant 0.42 Max DOC 6.000 OAL
Picture of INGERSOLL 1SJ1F-1503781R01 Milling Cutter 90.0° 1.500 Cylindrical 1.2500 3 Flute Coolant 0.42 Max DOC 6.000 OAL

INGERSOLL 1SJ1F-1503781R01 Milling Cutter 90.0° 1.500 Cylindrical 1.2500 3 Flute Coolant 0.42 Max DOC 6.000 OAL

ANSI: 1SJ1F-1503781R01

ISO: 1SJ1F-1503781R01

Need Assistance or Service? Please call 262-251-4020

Manufacturer: INGERSOLL
SKU: ING3030640
Delivery date: 3-5 days
$544.13

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Insert/Tool Tool
Application Face Milling, Side Milling
Package Size 1
Insert Application Roughing, Semi Finishing
Insert Type Negative
Made In USA No
Shipping State Illinois
Dimensional Specifications
Tool Material Steel
Cutter Dia 1.5000 38.10MM - 1-1/2
Machine Side Connection Type Cylindrical
Cut Dia Min 1.5000 38.10MM - 1-1/2
Insert Size Ic 31
Depth Of Cut Max 0.4200
Overall Len 6.0000 152.40MM
Shank/Pilot Dia 1.2500 31.75MM - 1-1/4
Flutes/Inserts 3
Machine Side Connection Size 1.2500 31.75MM
Cutting & Machining Properties
Insert Style DG
Coolant Thru Yes
Insert Shape/Cutter Pocket Shape Rectagonal
Max Ramp Angle 1.50°
