  • INGERSOLL 1KJ1G-1204281R01 Milling Cutter 90.0° 1.250 Cylindrical 1.2500 3 Flute Coolant 0.433 Max DOC 6.500 OAL
Picture of INGERSOLL 1KJ1G-1204281R01 Milling Cutter 90.0° 1.250 Cylindrical 1.2500 3 Flute Coolant 0.433 Max DOC 6.500 OAL

INGERSOLL 1KJ1G-1204281R01 Milling Cutter 90.0° 1.250 Cylindrical 1.2500 3 Flute Coolant 0.433 Max DOC 6.500 OAL

ANSI: 1KJ1G-1204281R01

ISO: 1KJ1G-1204281R01

Need Assistance or Service? Please call 262-251-4020

Manufacturer: INGERSOLL
SKU: ING3031386
Delivery date: 3-5 days
$409.73

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Application Ramp Milling, Side Milling, Pocket Milling, Face Milling, Slot Milling
Insert Application Roughing, Semi Finishing, Finishing
Made In USA No
Package Size 1
Insert/Tool Tool
Shipping State Illinois
Insert Type Positive
Dimensional Specifications
Cutter Dia 1.2500 31.75MM - 1-1/4
Depth Of Cut Max 0.4330
Insert Size Ic 10
Shank/Pilot Dia 1.2500 31.75MM - 1-1/4
Overall Len 6.5000 165.10MM
Flutes/Inserts 3
Cut Dia Min 1.2500 31.75MM - 1-1/4
Machine Side Connection Type Cylindrical
Tool Material Steel
Machine Side Connection Size 1.2500 31.75MM
Cutting & Machining Properties
Insert Style TH
Coolant Thru Yes
Insert Shape/Cutter Pocket Shape Triangle
