  • INGERSOLL 1KJ1D-0701184R01 Milling Cutter 90.0° 0.750 Weldon 0.7500 2 Flute Coolant 0.275 Max DOC 3.250 OAL
Picture of INGERSOLL 1KJ1D-0701184R01 Milling Cutter 90.0° 0.750 Weldon 0.7500 2 Flute Coolant 0.275 Max DOC 3.250 OAL

INGERSOLL 1KJ1D-0701184R01 Milling Cutter 90.0° 0.750 Weldon 0.7500 2 Flute Coolant 0.275 Max DOC 3.250 OAL

ANSI: 1KJ1D-0701184R01

ISO: 1KJ1D-0701184R01

Need Assistance or Service? Please call 262-251-4020

Manufacturer: INGERSOLL
SKU: ING3031477
Delivery date: 3-5 days
$316.40

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Application Ramp Milling, Slot Milling, Side Milling, Pocket Milling, Face Milling
Made In USA No
Shipping State Illinois
Insert Application Roughing, Semi Finishing, Finishing
Package Size 1
Insert/Tool Tool
Insert Type Positive
Dimensional Specifications
Insert Size Ic 6
Flutes/Inserts 2
Depth Of Cut Max 0.2750
Machine Side Connection Type Weldon
Cutter Dia 0.7500 19.05MM - 3/4
Tool Material Steel
Machine Side Connection Size 0.7500 19.05MM
Cut Dia Min 0.7500 19.05MM - 3/4
Shank/Pilot Dia 0.7500 19.05MM - 3/4
Overall Len 3.2500 82.55MM
Cutting & Machining Properties
Insert Style TH
Coolant Thru Yes
Max Ramp Angle 3.10°
Insert Shape/Cutter Pocket Shape Triangle
