  • INGERSOLL 1KJ1D-0601279R01 Milling Cutter 90.0° 0.625 Cylindrical 0.6250 1 Flute Coolant 0.275 Max DOC 3.250 OAL
Picture of INGERSOLL 1KJ1D-0601279R01 Milling Cutter 90.0° 0.625 Cylindrical 0.6250 1 Flute Coolant 0.275 Max DOC 3.250 OAL

INGERSOLL 1KJ1D-0601279R01 Milling Cutter 90.0° 0.625 Cylindrical 0.6250 1 Flute Coolant 0.275 Max DOC 3.250 OAL

ANSI: 1KJ1D-0601279R01

ISO: 1KJ1D-0601279R01

Need Assistance or Service? Please call 262-251-4020

Manufacturer: INGERSOLL
SKU: ING3031482
Delivery date: 3-5 days
$260.40

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Insert/Tool Tool
Application Pocket Milling, Face Milling, Slot Milling, Ramp Milling, Side Milling
Shipping State Illinois
Insert Application Roughing, Finishing, Semi Finishing
Made In USA No
Package Size 1
Insert Type Positive
Dimensional Specifications
Tool Material Steel
Cut Dia Min 0.6250 15.88MM - 5/8
Insert Size Ic 6
Flutes/Inserts 1
Machine Side Connection Size 0.6250 15.88MM
Overall Len 3.2500 82.55MM
Machine Side Connection Type Cylindrical
Cutter Dia 0.6250 15.88MM - 5/8
Depth Of Cut Max 0.2750
Shank/Pilot Dia 0.6250 15.88MM - 5/8
Cutting & Machining Properties
Insert Shape/Cutter Pocket Shape Triangle
Insert Style TH
Coolant Thru Yes
Max Ramp Angle 4.00°
