  • INGERSOLL 1BW7V-0704084R01 Milling Cutter 0.750 Weldon 0.7500 2 Flute Coolant 0.375 Max DOC 6.000 OAL
Picture of INGERSOLL 1BW7V-0704084R01 Milling Cutter 0.750 Weldon 0.7500 2 Flute Coolant 0.375 Max DOC 6.000 OAL

INGERSOLL 1BW7V-0704084R01 Milling Cutter 0.750 Weldon 0.7500 2 Flute Coolant 0.375 Max DOC 6.000 OAL

ANSI: 1BW7V-0704084R01

ISO: 1BW7V-0704084R01

Need Assistance or Service? Please call 262-251-4020

Manufacturer: INGERSOLL
SKU: ING3029884
Delivery date: 3-5 days
$399.47

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Insert Type Negative
Made In USA No
Shipping State Illinois
Insert Application Finishing, Semi Finishing
Application Profile Milling, Copy Milling
Package Size 1
Insert/Tool Tool
Dimensional Specifications
Cut Dia Min 0.7500 19.05MM - 3/4
Shank/Pilot Dia 0.7500 19.05MM - 3/4
Insert Size Ic 19
Depth Of Cut Max 0.3750
Flutes/Inserts 2
Machine Side Connection Type Weldon
Overall Len 6.0000 152.40MM
Cutter Dia 0.7500 19.05MM - 3/4
Tool Material Steel
Machine Side Connection Size 0.7500 19.05MM
Cutting & Machining Properties
Insert Style NK
Insert Shape/Cutter Pocket Shape Other
Coolant Thru Yes
