  • INGERSOLL 1A7G040R00 Milling Cutter Button Cutter 1.575 Shell Arbor 0.6300 5 Flute Coolant 0.1969 Max DOC 1.574 OAL
Picture of INGERSOLL 1A7G040R00 Milling Cutter Button Cutter 1.575 Shell Arbor 0.6300 5 Flute Coolant 0.1969 Max DOC 1.574 OAL

INGERSOLL 1A7G040R00 Milling Cutter Button Cutter 1.575 Shell Arbor 0.6300 5 Flute Coolant 0.1969 Max DOC 1.574 OAL

ANSI: 1A7G040R00

ISO: 1A7G040R00

Need Assistance or Service? Please call 262-251-4020

Manufacturer: INGERSOLL
SKU: ING3111232
Delivery date: 3-5 days
$572.13
Products specifications
Attribute name Attribute value
General Product Information
Insert Application Semi Finishing, Roughing
Insert/Tool Tool
Application Pocket Milling, Round Milling, Ramp Milling, Face Milling
Shipping State Illinois
Made In USA No
Package Size 1
Insert Type Positive
Dimensional Specifications
Insert Size Ic 10
Depth Of Cut Max 0.1969
Cutter Dia 1.5750 40.01MM
Tool Material Steel
Overall Len 1.5748 40.00MM
Flutes/Inserts 5
Cut Dia Min 1.1810 30.00MM
Machine Side Connection Type Face Mill/Shell Mill
Cut Dia Max 1.5750 40.01MM
Machine Side Connection Size 0.6299 16.00MM
Cutting & Machining Properties
Coolant Thru Yes
Insert Shape/Cutter Pocket Shape Round
Max Ramp Angle 5.00°
Insert Style RJ
