Picture of INGERSOLL 15U1G-10015X7R01 Milling Cutter 90.0° 1.000 Screw M12 2 Flute Coolant 0.41 Max DOC

INGERSOLL 15U1G-10015X7R01 Milling Cutter 90.0° 1.000 Screw M12 2 Flute Coolant 0.41 Max DOC

ANSI: 15U1G-10015X7R01

ISO: 15U1G-10015X7R01

Need Assistance or Service? Please call 262-251-4020

Manufacturer: INGERSOLL
SKU: ING3022765
Delivery date: 3-5 days
$390.13

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Insert Application Roughing, Semi Finishing
Made In USA No
Insert Type Positive
Application Slot Milling, Ramp Milling, Side Milling, Face Milling, Pocket Milling
Package Size 1
Insert/Tool Tool
Shipping State Illinois
Dimensional Specifications
Cutter Dia 1.0000 25.40MM
Flutes/Inserts 2
Machine Side Connection Type Screw On
Machine Side Connection Size M12
Depth Of Cut Max 0.4100
Insert Size Ic 11
Cut Dia Min 1.0000 25.40MM
Tool Material Steel
Cutting & Machining Properties
Coolant Thru Yes
Insert Style SH
Max Ramp Angle 2.00°
Insert Shape/Cutter Pocket Shape Square
