  • INGERSOLL 15B8E-12016X8R01 Milling Cutter Button Cutter 1.250 Screw M16 5 Flute Coolant 0.1575 Max DOC
Picture of INGERSOLL 15B8E-12016X8R01 Milling Cutter Button Cutter 1.250 Screw M16 5 Flute Coolant 0.1575 Max DOC

INGERSOLL 15B8E-12016X8R01 Milling Cutter Button Cutter 1.250 Screw M16 5 Flute Coolant 0.1575 Max DOC

ANSI: 15B8E-12016X8R01

ISO: 15B8E-12016X8R01

Need Assistance or Service? Please call 262-251-4020

Manufacturer: INGERSOLL
SKU: ING2919035
Delivery date: 3-5 days
$350.00

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Insert Application Semi Finishing, Roughing
Insert/Tool Tool
Application Face Milling, Ramp Milling, Pocket Milling, Round Milling
Package Size 1
Insert Type Positive
Shipping State Illinois
Made In USA No
Dimensional Specifications
Cutter Dia 1.2500 31.75MM - 1-1/4
Flutes/Inserts 5
Cut Dia Min 0.9350 23.75MM
Machine Side Connection Size M16
Tool Material Steel
Machine Side Connection Type Screw On
Insert Size Ic 8
Cut Dia Max 1.2500 31.75MM - 1-1/4
Depth Of Cut Max 0.1575
Cutting & Machining Properties
Insert Shape/Cutter Pocket Shape Round
Coolant Thru Yes
Max Ramp Angle 5.00°
Insert Style RJ
