  • INGERSOLL 12J1X-0801784R01 Milling Cutter 90.0° 0.875 Weldon 0.7500 2 Flute Coolant 0.49 Max DOC 3.750 OAL
Picture of INGERSOLL 12J1X-0801784R01 Milling Cutter 90.0° 0.875 Weldon 0.7500 2 Flute Coolant 0.49 Max DOC 3.750 OAL

INGERSOLL 12J1X-0801784R01 Milling Cutter 90.0° 0.875 Weldon 0.7500 2 Flute Coolant 0.49 Max DOC 3.750 OAL

ANSI: 12J1X-0801784R01

ISO: 12J1X-0801784R01

Need Assistance or Service? Please call 262-251-4020

Manufacturer: INGERSOLL
SKU: ING3024807
Delivery date: 3-5 days
$335.07

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Insert Application Roughing, Semi Finishing
Made In USA No
Package Size 1
Insert Type Positive
Application Face Milling, Slot Milling, Ramp Milling, Side Milling, Pocket Milling
Insert/Tool Tool
Shipping State Illinois
Dimensional Specifications
Insert Size Ic 12
Flutes/Inserts 2
Machine Side Connection Size 0.7500 19.05MM
Cut Dia Min 0.8750 22.23MM - 7/8
Shank/Pilot Dia 0.7500 19.05MM - 3/4
Depth Of Cut Max 0.4900
Machine Side Connection Type Weldon
Overall Len 3.7500 95.25MM
Cutter Dia 0.8750 22.23MM - 7/8
Tool Material Steel
Cutting & Machining Properties
Coolant Thru Yes
Insert Shape/Cutter Pocket Shape Parallelogram
Insert Style AO
Max Ramp Angle 5.50°
