  • INGERSOLL 12J1X-0702084R01 Milling Cutter 90.0° 0.725 Weldon 0.7500 2 Flute Coolant 0.49 Max DOC 4.000 OAL
Picture of INGERSOLL 12J1X-0702084R01 Milling Cutter 90.0° 0.725 Weldon 0.7500 2 Flute Coolant 0.49 Max DOC 4.000 OAL

INGERSOLL 12J1X-0702084R01 Milling Cutter 90.0° 0.725 Weldon 0.7500 2 Flute Coolant 0.49 Max DOC 4.000 OAL

ANSI: 12J1X-0702084R01

ISO: 12J1X-0702084R01

Need Assistance or Service? Please call 262-251-4020

Manufacturer: INGERSOLL
SKU: ING3024804
Delivery date: 3-5 days
$288.40

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Application Face Milling, Pocket Milling, Side Milling, Ramp Milling, Slot Milling
Package Size 1
Shipping State Illinois
Insert Application Semi Finishing, Roughing
Insert/Tool Tool
Made In USA No
Insert Type Positive
Dimensional Specifications
Cutter Dia 0.7250 18.42MM
Shank/Pilot Dia 0.7500 19.05MM - 3/4
Tool Material Steel
Depth Of Cut Max 0.4900
Machine Side Connection Type Weldon
Cut Dia Min 0.7250 18.42MM
Overall Len 4.0000 101.60MM
Machine Side Connection Size 0.7500 19.05MM
Insert Size Ic 12
Flutes/Inserts 2
Cutting & Machining Properties
Max Ramp Angle 7.00°
Insert Shape/Cutter Pocket Shape Parallelogram
Insert Style AO
Coolant Thru Yes
