  • INGERSOLL 12J1X-0701784R01 Milling Cutter 90.0° 0.750 Weldon 0.7500 2 Flute Coolant 0.49 Max DOC 3.750 OAL
Picture of INGERSOLL 12J1X-0701784R01 Milling Cutter 90.0° 0.750 Weldon 0.7500 2 Flute Coolant 0.49 Max DOC 3.750 OAL

INGERSOLL 12J1X-0701784R01 Milling Cutter 90.0° 0.750 Weldon 0.7500 2 Flute Coolant 0.49 Max DOC 3.750 OAL

ANSI: 12J1X-0701784R01

ISO: 12J1X-0701784R01

Need Assistance or Service? Please call 262-251-4020

Manufacturer: INGERSOLL
SKU: ING3024803
Delivery date: 3-5 days
$288.40

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Insert/Tool Tool
Application Pocket Milling, Face Milling, Slot Milling, Ramp Milling, Side Milling
Shipping State Illinois
Insert Application Roughing, Semi Finishing
Made In USA No
Package Size 1
Insert Type Positive
Dimensional Specifications
Tool Material Steel
Depth Of Cut Max 0.4900
Insert Size Ic 12
Flutes/Inserts 2
Cut Dia Min 0.7500 19.05MM - 3/4
Shank/Pilot Dia 0.7500 19.05MM - 3/4
Machine Side Connection Type Weldon
Overall Len 3.7500 95.25MM
Cutter Dia 0.7500 19.05MM - 3/4
Machine Side Connection Size 0.7500 19.05MM
Cutting & Machining Properties
Max Ramp Angle 7.00°
Insert Shape/Cutter Pocket Shape Parallelogram
Insert Style AO
Coolant Thru Yes
