IMCO 61141 DIA 1/4 SH 0.2500 LOC 0.3750 OAL 3.00 End Mill Standard Flute High Helix Carbide Uncoated Single End Ball Nose Streaker Mill

Need Assistance or Service? Please call 262-251-4020

Manufacturer: IMCO
SKU: IMC61141
Delivery date: 3-5 days
$56.52

Cutting Edge Definition

Cemented carbides are a class of hard materials used extensively for cutting tools, as well as in other industrial applications. It consists of fine particles of carbide cemented into a composite by a binder metal. Cemented carbides commonly use tungsten carbide (WC), titanium carbide (TiC), or tantalum carbide (TaC) as the aggregate. Mentions of "carbide" or "tungsten carbide" in industrial contexts usually refer to these cemented composites. The cobalt content could vary from 5% to 23% base on application. 8% to 12% are the most common for cutting tools. Ruthenium is used to replace cobalt as a perfered binder for the best cutting performance.

Products specifications
Attribute name Attribute value
General Product Information
Package Size 1
Application Profile Milling, Ball Slot Milling, Copy Milling, Side Milling, Ball Milling
Shipping State Ohio
Performance Rating High Performance
Made In USA Yes
Dimensional Specifications
Length Type Standard / With Neck
Flutes/Inserts 3
Dimension Description 0.250 x 0.250 x 0.375 x 3.000 LBS = 1.375
Cutter Style Carbide Ball Finisher
Single/Double End Single End
Shank/Pilot Dia 0.2500 6.35MM - 1/4 - E
Cut Rating Aluminum, Graphite, Plastic
Tool Material Carbide
Machine Side Connection Type Cylindrical
Machine Side Connection Size 0.2500 6.35MM
Inch/Metric Inch
Overall Len 3.0000 76.20MM
Length Of Cut 0.3750 9.53MM
Cutter Dia 0.2500 6.35MM - 1/4 - E
Neck Length 1.3750 34.93MM
End Of Tool Shape Ball Nose
Helix Angle 45°
Cutting & Machining Properties
Coolant Thru No
Center Cutting Yes
Cutting Edge Mat Carbide
Industry-Specific Applications
Medical Yes
Aerospace Yes
Job Shop Yes
