IMCO 61133 DIA 3/16 SH 0.1875 LOC 0.2500 OAL 3.00 End Mill Standard Flute High Helix Carbide Uncoated Single End Ball Nose Streaker Mill

Need Assistance or Service? Please call 262-251-4020

Manufacturer: IMCO
SKU: IMC61133
Delivery date: 3-5 days
$55.99

Cutting Edge Definition

Cemented carbides are a class of hard materials used extensively for cutting tools, as well as in other industrial applications. It consists of fine particles of carbide cemented into a composite by a binder metal. Cemented carbides commonly use tungsten carbide (WC), titanium carbide (TiC), or tantalum carbide (TaC) as the aggregate. Mentions of "carbide" or "tungsten carbide" in industrial contexts usually refer to these cemented composites. The cobalt content could vary from 5% to 23% base on application. 8% to 12% are the most common for cutting tools. Ruthenium is used to replace cobalt as a perfered binder for the best cutting performance.

Products specifications
Attribute name Attribute value
General Product Information
Made In USA Yes
Application Ball Milling, Side Milling, Ball Slot Milling, Profile Milling, Copy Milling
Package Size 1
Shipping State Ohio
Performance Rating High Performance
Dimensional Specifications
Neck Length 1.0000 25.40MM
Flutes/Inserts 3
Length Of Cut 0.2500 6.35MM
End Of Tool Shape Ball Nose
Machine Side Connection Size 0.1875 4.76MM
Helix Angle 45°
Shank/Pilot Dia 0.1875 4.76MM - 3/16
Length Type Standard / With Neck
Dimension Description 0.188 x 0.188 x 0.250 x 3.000 LBS = 1.000
Overall Len 3.0000 76.20MM
Cutter Style Carbide Ball Finisher
Single/Double End Single End
Cut Rating Aluminum, Graphite, Plastic
Cutter Dia 0.1875 4.76MM - 3/16
Tool Material Carbide
Machine Side Connection Type Cylindrical
Inch/Metric Inch
Cutting & Machining Properties
Cutting Edge Mat Carbide
Coolant Thru No
Center Cutting Yes
Industry-Specific Applications
Aerospace Yes
Job Shop Yes
Medical Yes
