IMCO 61121 DIA 1 SH 1.00 LOC 2.00 OAL 5.00 End Mill Standard Flute High Helix Carbide Uncoated Single End Corner Radius 0.0300 0.76MM Streaker Mill

Need Assistance or Service? Please call 262-251-4020

Manufacturer: IMCO
SKU: IMC61121
Delivery date: 3-5 days
$440.30

Cutting Edge Definition

Cemented carbides are a class of hard materials used extensively for cutting tools, as well as in other industrial applications. It consists of fine particles of carbide cemented into a composite by a binder metal. Cemented carbides commonly use tungsten carbide (WC), titanium carbide (TiC), or tantalum carbide (TaC) as the aggregate. Mentions of "carbide" or "tungsten carbide" in industrial contexts usually refer to these cemented composites. The cobalt content could vary from 5% to 23% base on application. 8% to 12% are the most common for cutting tools. Ruthenium is used to replace cobalt as a perfered binder for the best cutting performance.

Products specifications
Attribute name Attribute value
General Product Information
Application Side Milling, Copy Milling, Face Milling, Profile Milling, Slot Milling
Shipping State Ohio
Package Size 1
Made In USA Yes
Performance Rating High Performance
Dimensional Specifications
Dimension Description 1.000 x 1.000 x 2.000 x 5.000
Machine Side Connection Type Cylindrical
Overall Len 5.0000 127.00MM
Length Of Cut 2.0000 50.80MM
Cut Rating Aluminum, Graphite, Plastic
Tool Material Carbide
Machine Side Connection Size 1.0000 25.40MM
Shank/Pilot Dia 1.0000 25.40MM
Inch/Metric Inch
Flutes/Inserts 3
Cutter Style Carbide Bull Nose Finisher
Cutter Dia 1.0000 25.40MM
Length Type Standard
Helix Angle 45°
Corner Radius 0.0300 0.76MM
End Of Tool Shape Corner Radius
Single/Double End Single End
Cutting & Machining Properties
Coolant Thru No
Cutting Edge Mat Carbide
Center Cutting Yes
Industry-Specific Applications
Aerospace Yes
Job Shop Yes
Medical Yes
