ICE APMT1135PDER-M2L IC3115D Milling Insert Parallelogram 0.031 Corner Radius

Need Assistance or Service? Please call 262-251-4020

Manufacturer: ICE
SKU: ICE89856
Delivery date: 3-5 days
Call (262) 251-4020 for pricing

Cutting Edge Definition

Cemented carbides are a class of hard materials used extensively for cutting tools, as well as in other industrial applications. It consists of fine particles of carbide cemented into a composite by a binder metal. Cemented carbides commonly use tungsten carbide (WC), titanium carbide (TiC), or tantalum carbide (TaC) as the aggregate. Mentions of "carbide" or "tungsten carbide" in industrial contexts usually refer to these cemented composites. The cobalt content could vary from 5% to 23% base on application. 8% to 12% are the most common for cutting tools. Ruthenium is used to replace cobalt as a perfered binder for the best cutting performance.

Grade and Coating Description

HIGH SPEED CUTTING OF CAST IRON

Products specifications
Attribute name Attribute value
General Product Information
Package Size 10
Shipping State Wisconsin
Made In USA No
Application Milling Insert
Grade IC3115D
Dimensional Specifications
Insert Size Ic 11
Corner Radius 0.0310 0.79MM
Cut Rating Ductile Iron, Gray Iron
Cutting & Machining Properties
Cutting Edge Mat Carbide
Insert Style AP
