ICE-ECO-025-4-35-0625-BN-WLDN-BRITE-DE-R DIA 1/4 SH 0.2500 LOC 0.6250 OAL 4.00 End Mill Standard Flute Standard Helix Carbide Double End Ball Nose Blue

Need Assistance or Service? Please call 262-251-4020

Manufacturer: ICE
SKU: ICE788395
Delivery date: 3-5 days
$37.69

Cutting Edge Definition

Cemented carbides are a class of hard materials used extensively for cutting tools, as well as in other industrial applications. It consists of fine particles of carbide cemented into a composite by a binder metal. Cemented carbides commonly use tungsten carbide (WC), titanium carbide (TiC), or tantalum carbide (TaC) as the aggregate. Mentions of "carbide" or "tungsten carbide" in industrial contexts usually refer to these cemented composites. The cobalt content could vary from 5% to 23% base on application. 8% to 12% are the most common for cutting tools. Ruthenium is used to replace cobalt as a perfered binder for the best cutting performance.

Products specifications
Attribute name Attribute value
General Product Information
Application Copy Milling, Side Milling, Ball Slot Milling, Profile Milling, Ball Milling
Package Size 1
Shipping State Wisconsin
Made In USA No
Performance Rating General Performance
Dimensional Specifications
Tool Material Carbide
Machine Side Connection Type Weldon
Flute Length 0.6250 15.88MM
Inch/Metric Inch
Single/Double End Double End
Overall Len 4.0000 101.60MM
Helix Angle 30°
Cut Rating <42HRC, Cast Iron, Stainless
Cutter Dia 0.2500 6.35MM - 1/4 - E
End Of Tool Shape Ball Nose
Shank/Pilot Dia 0.2500 6.35MM - 1/4 - E
Cutter Style Carbide Ball Finisher
Dimension Description 0.250 x 0.250 x 0.625 x 4.000
Flutes/Inserts 4
Length Of Cut 0.6250 15.88MM
Length Type Standard
Machine Side Connection Size 0.2500 6.35MM
Cutting & Machining Properties
Cutting Edge Mat Carbide
Center Cutting Yes
Coolant Thru No
Industry-Specific Applications
Agricultural YES
Energy Yes
Automotive Yes
Job Shop Yes
Contractor Yes
