Picture of HTC 199-4750 Dia 3/4 SH 0.7500 LOC 0.8750 OAL4.00 End Mill Standard Flute Standard Helix Carbide TiN Double End Ball NoseBall

HTC 199-4750 Dia 3/4 SH 0.7500 LOC 0.8750 OAL4.00 End Mill Standard Flute Standard Helix Carbide TiN Double End Ball NoseBall

Part Number: HTC199-4750 0.750 x 0.750 x 0.875 x 4.000

Need Assistance or Service? Please call 262-251-4020

Manufacturer: HTC
SKU: 1246479
Vendor: Sussex Tool and Supply
$122.00
HTC Standard Helix End Mill Carbide TiN Ball Nose Ball Standard Flute Flutes 4 Double End HTC Carbide Titanium nitride (TiN) coating is wear resistant, inert & reduces friction. Used on cutting tools punches etc improving tool life 2-10x over uncoated tools
Products specifications
Attribute name Attribute value
Shipping State MICHIGAN
Made In USA YES
Cutter Type Solid End Mill
Tool Material Carbide
Cutting Edge Mat Carbide
Machine Side Connection Type Cylindrical
Cut Rating Stainless Steel, Gray Iron, Ductile Iron, <42HRC Steel
Coating TIN
Mach Side Connection Size 0.7500 19.05MM
Overall Length 4.0000 101.60MM
Coolant Thru Non Coolant
Shank/Pilot Dia 0.7500 19.05MM - 3/4
Flutes/Inserts 4
Tool Dia 0.7500 19.05MM - 3/4
Length Type STANDARD
Performance Rating General Performance
Length Of Cut 0.8750 22.23MM
End Of Tool Shape Ball Nose
Cutter Style Carbide Ball Finisher
Single/Double End Double End
Inch/Metric Inch
Helix Angle 30
Center Cutting Center Cutting
