HTC 195-2562 DIA 9/16 SH 0.6250 LOC 0.6875 OAL 3.50 End Mill Standard Flute Standard Helix Carbide Uncoated Double End Ball Nose

Need Assistance or Service? Please call 262-251-4020

Manufacturer: HTC
SKU: HTC195-2562
Delivery date: 3-5 days
$80.57

Cutting Edge Definition

Cemented carbides are a class of hard materials used extensively for cutting tools, as well as in other industrial applications. It consists of fine particles of carbide cemented into a composite by a binder metal. Cemented carbides commonly use tungsten carbide (WC), titanium carbide (TiC), or tantalum carbide (TaC) as the aggregate. Mentions of "carbide" or "tungsten carbide" in industrial contexts usually refer to these cemented composites. The cobalt content could vary from 5% to 23% base on application. 8% to 12% are the most common for cutting tools. Ruthenium is used to replace cobalt as a perfered binder for the best cutting performance.

Products specifications
Attribute name Attribute value
General Product Information
Package Size 1
Application Ball Slot Milling, Ball Milling, Side Milling, Profile Milling, Copy Milling
Made In USA Yes
Shipping State Michigan
Performance Rating General Performance
Dimensional Specifications
Cutter Dia 0.5625 14.29MM - 9/16
Flutes/Inserts 2
Dimension Description 0.563 x 0.625 x 0.688 x 3.500
Cut Rating <42HRC Steel, Ductile Iron, Gray Iron, Stainless Steel
Overall Len 3.5000 88.90MM
Shank/Pilot Dia 0.6250 15.88MM - 5/8
End Of Tool Shape Ball Nose
Helix Angle 30°
Single/Double End Double End
Machine Side Connection Size 0.6250 15.88MM
Cutter Style Carbide Ball Finisher
Tool Material Carbide
Machine Side Connection Type Cylindrical
Length Of Cut 0.6875 17.46MM
Inch/Metric Inch
Length Type Standard
Cutting & Machining Properties
Coolant Thru No
Cutting Edge Mat Carbide
Center Cutting Yes
Industry-Specific Applications
Job Shop Yes
