HARVEY Tool 34316 DIA 1/4 LOC 0.3750 OAL 4.00 End Mill Standard Flute Standard Helix Carbide Uncoated Single End Square Sharp

Need Assistance or Service? Please call 262-251-4020

Manufacturer: HARVEY TOOL
SKU: HAR34316
Delivery date: 3-5 days
$56.00

Cutting Edge Definition

Cemented carbides are a class of hard materials used extensively for cutting tools, as well as in other industrial applications. It consists of fine particles of carbide cemented into a composite by a binder metal. Cemented carbides commonly use tungsten carbide (WC), titanium carbide (TiC), or tantalum carbide (TaC) as the aggregate. Mentions of "carbide" or "tungsten carbide" in industrial contexts usually refer to these cemented composites. The cobalt content could vary from 5% to 23% base on application. 8% to 12% are the most common for cutting tools. Ruthenium is used to replace cobalt as a perfered binder for the best cutting performance.

Products specifications
Attribute name Attribute value
General Product Information
Application Counterboring, Face Milling, Shoulder Milling, Slot Milling
Shipping State Massachusetts
Made In USA Yes
Performance Rating General Performance
Package Size 1
Dimensional Specifications
Single/Double End Single End
Overall Len 4.0000 101.60MM
Length Of Cut 0.3750 9.53MM
Cut Rating <48HRC Steel, Gray Iron, Stainless Steel
Cutter Dia 0.2500 6.35MM - 1/4 - E
Length Type Standard / With Neck
Tool Material Carbide
Machine Side Connection Type Cylindrical
Machine Side Connection Size 0.2500 6.35MM
Cutter Style Carbide Finisher
Inch/Metric Inch
Shank/Pilot Dia 0.2500 6.35MM - 1/4 - E
Taper Flute No
Flutes/Inserts 3
End Of Tool Shape Square
Dimension Description 0.250 x 0.250 x 0.375 x 4.000
Neck Length 2.0000 50.80MM
Cutting & Machining Properties
Cutting Edge Mat Carbide
Coolant Thru No
