Picture of EVEREDE Tool TDAB-07 CT7 Positive Triangle Insert

EVEREDE Tool TDAB-07 CT7 Positive Triangle Insert

ANSI: TDHB 130805 CT7

ISO: TDAB-07 CT7

Need Assistance or Service? Please call 262-251-4020

Manufacturer: EVEREDE TOOL
SKU: EVE04054
Delivery date: 3-5 days
$12.28

Cutting Edge Definition

Cermet is a cutting material combining ceramics and metals (usualט Nickel). The result is a harder substrate than carbide, therefore more wear-resistant, and enables machining at higher cutting speeds. The downside is very low toughness, and therefore, it is used only for finishing applications in stable conditions. Some tougher versions are available today for semi roughing. Used very often in Duplex milling.

Grade and Coating Description

Cermet P05 steel, stainless and cast iron finishing application.

Products specifications
Attribute name Attribute value
General Product Information
Application Turning Insert
Made In USA No
Insert/Tool Insert
Insert Application Finishing, Semi Finishing
Insert Type Positive
Shipping State Illinois
Grade CT7
Package Size 10
Dimensional Specifications
Corner Radius 0.0070 0.18MM
Cut Rating <30HRC Steel, Gray Iron, Stainless Steel
Insert Size Ic 07 "13"
Cutting & Machining Properties
Insert Shape/Cutter Pocket Shape Triangle
Cutting Edge Mat Cermet
Insert Style TD
