Picture of EVEREDE Tool SC3080L Triangle Boring Bar Dia0.7500 Positive 0.3750 9.53MM - 3/8 Cutter Dia

EVEREDE Tool SC3080L Triangle Boring Bar Dia0.7500 Positive 0.3750 9.53MM - 3/8 Cutter Dia

ANSI: SC3080L

ISO: SC3080L

Need Assistance or Service? Please call 262-251-4020

Manufacturer: EVEREDE TOOL
SKU: EVE00520
Delivery date: 3-5 days
$127.81
Products specifications
Attribute name Attribute value
General Product Information
Insert Application General Purpose
Made In USA No
Shipping State Illinois
Insert/Tool Tool
Package Size 1
Insert Type Positive
Application Int.Turning
Dimensional Specifications
Cutter Dia 0.3750 9.53MM - 3/8
Min Bore 0.4380
Overall Len 4.0000 101.60MM
Machine Side Connection Type Boring Bar
Tool Material Steel
Machine Side Connection Size 0.7500 19.05MM
Shank/Pilot Dia 0.7500 19.05MM - 3/4
Lead Angle 95°
Insert Size Ic 21
Cutting & Machining Properties
Inter/Extern Internal
Hand R/L Left
Insert Style TP
Insert Shape/Cutter Pocket Shape Triangle
