EMUGE GFR15106.5016 Carbide Thread Mill 3/4" x10.00TPI Carbide TICN

Need Assistance or Service? Please call 262-251-4020

Manufacturer: EMUGE
SKU: EMUGFR15106.5016
Delivery date: 3-5 days
$438.74

Cutting Edge Definition

Cemented carbides are a class of hard materials used extensively for cutting tools, as well as in other industrial applications. It consists of fine particles of carbide cemented into a composite by a binder metal. Cemented carbides commonly use tungsten carbide (WC), titanium carbide (TiC), or tantalum carbide (TaC) as the aggregate. Mentions of "carbide" or "tungsten carbide" in industrial contexts usually refer to these cemented composites. The cobalt content could vary from 5% to 23% base on application. 8% to 12% are the most common for cutting tools. Ruthenium is used to replace cobalt as a perfered binder for the best cutting performance.

Products specifications
Attribute name Attribute value
General Product Information
Performance Rating High Performance
Application Thread Milling
Made In USA No
Package Size 1
Coating TiCN
Shipping State Massachusetts
Dimensional Specifications
Thread Size 3/4"
Cut Rating <40HRC, Stainless, Iron, High Temp
Shank/Pilot Dia 0.6250 15.88MM - 5/8
Cutter Dia 0.6210 15.77MM
Overall Len 4.2500 107.95MM
Machine Side Connection Size 0.6250 15.88MM
Thread Pitch 10.00TPI
Tool Material Carbide
Machine Side Connection Type Cylindrical
Length Of Cut 1.5480 39.32MM
Cutting & Machining Properties
Cutting Edge Mat Carbide
Coolant Thru No
Industry-Specific Applications
Aerospace Yes
Job Shop Yes
Automotive Yes
Medical Yes
Energy Yes
