Picture of DORIAN SNR075-07-16 Iso Thread Boring Bar 0.750 Shank 7.000 OAL

DORIAN SNR075-07-16 Iso Thread Boring Bar 0.750 Shank 7.000 OAL

ANSI: SNR075-07-16

ISO: SNR075-07-16

Need Assistance or Service? Please call 262-251-4020

Manufacturer: DORIAN
SKU: DOR58636
Delivery date: 3-5 days
$100.93
Products specifications
Attribute name Attribute value
General Product Information
Application Int.Threading, Int.Groove Threading
Made In USA No
Insert Application General Purpose
Shipping State Texas
Insert/Tool Insert
Insert Type Positive
Package Size 1
Dimensional Specifications
Tool Material Steel
Machine Side Connection Type Boring Bar
Min Bore 0.9500
Insert Size Ic 16
Shank/Pilot Dia 0.7500 19.05MM - 3/4
Overall Len 7.0000 177.80MM
Machine Side Connection Size 0.7500 19.05MM
Cutting & Machining Properties
Coolant Thru No
Insert Style ISO
Hand R/L Right
Inter/Extern Internal
Insert Shape/Cutter Pocket Shape Triangle
Fasteners & Connectors
Seat Screw GXE-16
Insert Screw TS-16
