Picture of DORIAN SCACL08-3D 80.0° Swiss Square 0.500 Shank 6.000 OAL

DORIAN SCACL08-3D 80.0° Swiss Square 0.500 Shank 6.000 OAL

ANSI: SCACL08-3D

ISO: SCACL08-3D

Need Assistance or Service? Please call 262-251-4020

Manufacturer: DORIAN
SKU: DOR51783
Delivery date: 3-5 days
$86.34

Features And Benefits

Qualified toolholder stop for repeatability when indexing an insert Zero tolerance when moved, locked & repositioned

Details

Non Thru Coolant toolholder for swiss turning

Products specifications
Attribute name Attribute value
General Product Information
Insert Application General Purpose
Application Swiss, Ext.Turning
Made In USA No
Insert/Tool Tool
Shipping State Texas
Insert Type Positive
Package Size 1
Dimensional Specifications
Overall Len 6.0000 152.40MM
Tool Width 0.5000
Insert Size Ic 09 "32"
Machine Side Connection Type Stick Tool
Shank/Pilot Dia 0.5000 12.70MM - 1/2
Tool Material Steel
Lead Angle 93°
Machine Side Connection Size 0.5000 12.70MM
Tool Over Hang 1.0000
Cutting & Machining Properties
Insert Style CC
Coolant Thru No
Insert Shape/Cutter Pocket Shape 80.0°
Hand R/L Left
Inter/Extern External
