Picture of DORIAN ASGTHR1212-H02 Stick Tool Press In Square 0.472 Shank 3.940 OAL

DORIAN ASGTHR1212-H02 Stick Tool Press In Square 0.472 Shank 3.940 OAL

ANSI: ASGTHR1212-H02

ISO: ASGTHR1212-H02

Need Assistance or Service? Please call 262-251-4020

Manufacturer: DORIAN
SKU: DOR62924
Delivery date: 3-5 days
$119.45

Features And Benefits

Qualified toolholder stop for repeatability when indexing an insert Zero tolerance when moved, locked & repositioned

Details

Quick-Disconnect Thru Coolant toolholder single sided SGTN or GTN inserts

Products specifications
Attribute name Attribute value
General Product Information
Package Size 1
Insert/Tool Tool
Application Ext.Grooving, Parting, Swiss
Insert Type Positive
Shipping State Texas
Insert Application General Purpose
Made In USA No
Dimensional Specifications
Machine Side Connection Size 0.4724 12.00MM
Insert Size Ic 2
Tool Material Steel
Machine Side Connection Type Stick Tool
Overall Len 3.9400 100.08MM
Shank/Pilot Dia 0.4724 12.00MM
Tool Over Hang 3.9370
Tool Width 0.4720
Cutting & Machining Properties
Insert Style SG
Coolant Thru Yes
Inter/Extern External
Insert Shape/Cutter Pocket Shape Other
Hand R/L Right
