Picture of DORIAN ADLER16-22Q-D Iso Thread Square 1.000 Shank 6.000 OAL

DORIAN ADLER16-22Q-D Iso Thread Square 1.000 Shank 6.000 OAL

ANSI: ADLER16-22Q-D

ISO: ADLER16-22Q-D

Need Assistance or Service? Please call 262-251-4020

Manufacturer: DORIAN
SKU: DOR53528
Delivery date: 3-5 days
$173.63
Products specifications
Attribute name Attribute value
General Product Information
Insert/Tool Tool
Application Ext.Groove Threading, Ext.Threading
Package Size 1
Insert Type Positive
Shipping State Texas
Insert Application General Purpose
Made In USA No
Dimensional Specifications
Tool Material Steel
Machine Side Connection Type Stick Tool
Insert Size Ic 22
Machine Side Connection Size 1.0000 25.40MM
Shank/Pilot Dia 1.0000 25.40MM
Tool Width 1.0000
Overall Len 6.0000 152.40MM
Cutting & Machining Properties
Coolant Thru Yes
Seat/Nest NXE-22
Inter/Extern External
Insert Shape/Cutter Pocket Shape Triangle
Insert Style ISO
Hand R/L Right
Fasteners & Connectors
Clamp/Wedge JSLC-HP22N
Insert Screw TS-45.75-15M1
Clamp Screw JSCS-04
