Picture of DORIAN ADDN-TFR-1616-H30-09 Stick Tool Clamp Down Square 0.629 Shank 4.210 OAL

DORIAN ADDN-TFR-1616-H30-09 Stick Tool Clamp Down Square 0.629 Shank 4.210 OAL

ANSI: ADDN-TFR-1616-H30-09

ISO: ADDN-TFR-1616-H30-09

Need Assistance or Service? Please call 262-251-4020

Manufacturer: DORIAN
SKU: DOR61006
Delivery date: 3-5 days
$122.31

Features And Benefits

Qualified toolholder stop for repeatability when indexing an insert Zero tolerance when moved, locked & repositioned

Details

Quick-Disconnect Thru Coolant toolholder for double sided part-off inserts

Products specifications
Attribute name Attribute value
General Product Information
Insert/Tool Tool
Application Ext.Grooving, Parting, Swiss
Insert Type Positive
Insert Application General Purpose
Made In USA No
Package Size 1
Shipping State Texas
Dimensional Specifications
Tool Material Steel
Machine Side Connection Type Stick Tool
Machine Side Connection Size 0.6299 16.00MM
Overall Len 4.2100 106.93MM
Shank/Pilot Dia 0.6299 16.00MM
Tool Over Hang 1.2600
Insert Size Ic 30
Tool Width 0.6300
Cutting & Machining Properties
Coolant Thru Yes
Insert Style DN
Insert Shape/Cutter Pocket Shape Other
Inter/Extern External
Hand R/L Right
