Picture of DORIAN ADCLNL-20-5D 80.0° Square 1.250 Shank 6.000 OAL

DORIAN ADCLNL-20-5D 80.0° Square 1.250 Shank 6.000 OAL

ANSI: ADCLNL-20-5D

ISO: ADCLNL-20-5D

Need Assistance or Service? Please call 262-251-4020

Manufacturer: DORIAN
SKU: DOR53007
Delivery date: 3-5 days
$189.91

Details

Neg 80°Jet Stream Toolholder L

Products specifications
Attribute name Attribute value
General Product Information
Insert/Tool Tool
Insert Application General Purpose
Insert Type Negative
Made In USA No
Application Ext.Turning
Package Size 1
Shipping State Texas
Dimensional Specifications
Tool Material Steel
Machine Side Connection Type Stick Tool
Machine Side Connection Size 1.2500 31.75MM
Tool Width 1.2500
Lead Angle 95°
Overall Len 6.0000 152.40MM
Insert Size Ic 16 "54"
Shank/Pilot Dia 1.2500 31.75MM - 1-1/4
Cutting & Machining Properties
Insert Style CN
Inter/Extern External
Insert Shape/Cutter Pocket Shape 80.0°
Hand R/L Left
Cool Sply Type Through
Coolant Thru Yes
Fasteners & Connectors
Insert Screw SM-M6
Clamp/Wedge JSLC-HPC5
Clamp Screw JSCS-04
Seat Screw JC-533
