  • DIJET SEC-2150-2.5-S125 Milling Cutter 90.0°, Drill Mill 1.500 Cutter Diameter Weldon 1.250 Shank 6.500 OAL 6 Flute
Picture of DIJET SEC-2150-2.5-S125 Milling Cutter 90.0°, Drill Mill 1.500 Cutter Diameter Weldon 1.250 Shank 6.500 OAL 6 Flute

DIJET SEC-2150-2.5-S125 Milling Cutter 90.0°, Drill Mill 1.500 Cutter Diameter Weldon 1.250 Shank 6.500 OAL 6 Flute

ANSI: SEC-2150-2.5-S125

ISO: SEC-2150-2.5-S125

Need Assistance or Service? Please call 262-251-4020

Manufacturer: DIJET
SKU: DIJSEC-2150-2.5-S125
Delivery date: 3-5 days
$692.65
Products specifications
Attribute name Attribute value
General Product Information
Insert/Tool Tool
Application Drilling, Pocket Milling, Ramp Milling, Slot Milling, Side Milling, Plunge Milling, Shoulder Milling
Made In USA No
Insert Application Semi Finishing, Roughing
Insert Type Positive
Shipping State Michigan
Package Size 1
Dimensional Specifications
Depth Of Cut Max 2.5000
Shank/Pilot Dia 1.2500 31.75MM - 1-1/4
Length Of Cut 2.5000 63.50MM
Tool Material Steel
Overall Len 6.5000 165.10MM
Dimension Description 1.500 x 1.250 x 2.500 x 6.500
Machine Side Connection Size 1.2500 31.75MM
Machine Side Connection Type Weldon
Insert Size Ic 19
Cutter Dia 1.5000 38.10MM - 1-1/2
Flutes/Inserts 6
Cutting & Machining Properties
Insert Style ZD,ZP
Insert Shape/Cutter Pocket Shape Other
Fasteners & Connectors
Insert Screw DSW-4510H
