Picture of DGN 4003C IC30N Iscar 6002529 Cut Off,Grooving Insert 0.1220 3.10mm Wide 0.0080 0.20mm Radius

DGN 4003C IC30N Iscar 6002529 Cut Off,Grooving Insert 0.1220 3.10mm Wide 0.0080 0.20mm Radius

Part Number: ISC6002529 ISO: DGN 4003C IC30N ANSI:DGN 4003C IC30N

Need Assistance or Service? Please call 262-251-4020

Manufacturer: ISCAR
SKU: 1082145
Vendor: Sussex Tool and Supply
$24.23
This product has a minimum quantity of 10
ISCAR 6002529 Dog Bone Cut Off,Grooving Positive Uncoated Cermet grade. Provides excellent resistance to wear and plastic deformation even at high cutting speeds and medium feeds. Useful for semi finishing and finishing.
Products specifications
Attribute name Attribute value
Shipping State TEXAS
Made In USA NO
Cutter Type Insert
Cutting Edge Mat Cermet
Cut Rating <48HRC Steel, Stainless Steel
Insert/Tool INSERT
Cut Type General Purpose
Corner Radius 0.0080 0.20MM
Insert Style DG
Insert Shape/Cutter Pocket Shape Dog Bone
Grade IC30N
Insert Type Positive
Insert Size Ic 4
Depth Of Cut Max 0.7090
Insert Type/Oriantation Clamp Down
Cutting Width 0.1220 3.10MM
