Picture of DAPRA GWR10-130-10-RZ Ball Mill,Back Draft 0.394 Cutter Diameter Weldon 0.393 Shank 5.120 OAL

DAPRA GWR10-130-10-RZ Ball Mill,Back Draft 0.394 Cutter Diameter Weldon 0.393 Shank 5.120 OAL

ANSI: GWR10-130-10-RZ

ISO: GWR10-130-10-RZ

Need Assistance or Service? Please call 262-251-4020

Manufacturer: DAPRA
SKU: DAP50010
Delivery date: 3-5 days
$214.05

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Insert/Tool Tool
Shipping State Connecticut
Insert Application Finishing, Semi Finishing
Application Profile Milling, Copy Milling
Insert Type Neutral
Made In USA Yes
Package Size 1
Dimensional Specifications
Insert Size Ic 10
Tool Material Steel
Machine Side Connection Size 0.3937 10.00MM
Cutter Dia 0.3940 10.01MM
Overall Len 5.1200 130.05MM
Machine Side Connection Type Weldon
Shank/Pilot Dia 0.3937 10.00MM
Cutting & Machining Properties
Insert Style BD,BN,FB,HB,RD,HF
Inter/Extern External
Hand R/L Right
Insert Shape/Cutter Pocket Shape Flat Blade
Fasteners & Connectors
Insert Screw GWS 10
