AWARD BO-1624TIN DIA 1 SH 2.00 LOC 6.00 OAL 9.50 End Mill Taper Flute HSS TiN Single End Square Sharp

Need Assistance or Service? Please call 262-251-4020

Manufacturer: AWARD
SKU: AWABO-1624TIN
Delivery date: 3-5 days
$580.89

Cutting Edge Definition

High speed steels (often abbreviated HSS) are ferrous based alloys of the Fe–C–X multicomponent system where X represents a group of alloying elements comprising mainly Cr, W or Mo, V, and Co. These steels are mainly used for cutting tools, since they are characterized by their capacity to retain a high level of hardness while cutting metals at high speed. Generally, the X component is present in excess of 7%, along with more than 0.60% carbon.

Grade and Coating Description

Titanium nitride (TiN) coating is wear resistant, inert & reduces friction. Used on cutting tools punches etc improving tool life 2-10x over uncoated tools

Products specifications
Attribute name Attribute value
General Product Information
Performance Rating General Performance
Application Copy Milling, Profile Milling, Taper Side Milling, Face Milling
Coating TiN
Shipping State Michigan
Package Size 1
Made In USA Yes
Dimensional Specifications
End Of Tool Shape Square
Machine Side Connection Type Cylindrical
Inch/Metric Inch
Cut Dia Max 2.0499 52.07MM
Machine Side Connection Size 2.0000 50.80MM
Cutter Dia 1.0000 25.40MM
Tool Material High Speed Steel
Flutes/Inserts 4
Length Of Cut 6.0000 152.40MM
Length Type Standard
Shank/Pilot Dia 2.0000 50.80MM - 2
Taper Angle 5.0°
Single/Double End Single End
Dimension Description 1.000 x 2.000 x 6.000 x 9.500
Overall Len 9.5000 241.30MM
Cutter Style Taper Flute Finisher
Helix Angle 30°
Cut Rating <40HRC Steel, Aluminum, Ductile Iron, Gray Iron
Taper Flute Yes
Cutting & Machining Properties
Center Cutting No
Coolant Thru No
Cutting Edge Mat HSS
Industry-Specific Applications
Aerospace Yes
Automotive Yes
Job Shop Yes
Mold Yes
Energy Yes
Agricultural YES
